Wired (MPEG-4) Video Server IP-SUS110
Specification | ||
Model/Code NO. | IP-SUS110 | |
Hardware | CPU | 32Bit RSIC Embedded Processor |
OS | Embedded Linux system | |
Network | Protocol | Support TCP/IP, HTTP, ARP, ARP, etc. |
Interface | RJ45 10/100M | |
Video | Compression | MPEG-4 |
Frame Rate | 10-25fps (D1) | |
Resolution | D1: 720×576 CIF: 320×288 FIELD: 720×288 QCIF: 192×144 | |
Input | 1Ch | |
Output | 1Ch | |
Audio Input | 1Ch | |
Alarm/Recording | Motion detection, Alarm input, Output. Schedule and Manual Recording | |
Pan/Tilt Control | RS485 | |
Security | Account number, password, user privilege | |
Power Supply | DC 12V, 1A | |
Size | 104x97x40mm |
